GEDA TP 1100 – TRANSPORT PLATFORM

Price on request

Request this product

Didn't find the right configuration? Or would you rather rent?

The GEDA TP 1100 transport platform has been specifically designed for use

in tough building site conditions and is extremely flexible. With two separate

controls, it can be used simply as a material hoist or as a transport platform for

passengers and materials.

A lifting speed of 80 ft/min in material mode and 40 ft/min in passenger mode

ensures rapid construction progress.

The TP 1100 transport platform is an indispensable aid for rapid assembly

of scaffolding as well as for the subsequent work at the construction site.

With minimal space requirements, high load capacity and various application

options, the construction hoist saves time and ensures optimum logistics

processes on site.

Every construction site has its own challenges. Different platform versions with

different loading doors and flaps therefore allow optimum adaptation of the

GEDA TP 1100 to the requirements on site. The spacious loading platform

without cover provides sufficient space for all types of construction materials.

Load up to: 1100/1875 lbs - 500 /850 kg

4 persons

Height up to: 330 ft – 100 m

Lift speed up to: 40/80 ft/min – 12-24 m/min

Power: 4/8 hp/480 V/60 Hz/16 A
